Seamless vacuum bag made of transparent PA/PP/PA multilayered composite film (co-extruded polyamide film).

The film has an exceptionally good form-fitting capacity, especially for difficult contours with strong undercuts, and thus enables the moulding of complex components. It has auto-release properties and can be used in direct contact with the resin.
epoxy or polyester.

• Absolutely air-tight
• Self-releasing
• Styrene-resistant
• Diffusion-resistant
• High-temperature resistance
• Can be used with all common resin systems
• Suitable for vacuum pressing and vacuum infusion

Technical data:
Max. temperature: 180 °C*
Thickness: 50 µm
Width: 60 cm
Elongation at break: approx. 360 %

Material (3 layers):
Outer: Two self-separating copolymer layers
Inner: One copolyamide layer
Colour: Pink

*Maximum service temperature is dependent upon the duration and is process-specific. We recommend testing prior to use. The tolerance amounts ± 3 %.

To close, the open ends are simply folded and fixed several times. A permanently elastic sealing compound (e.g. R&G vacuum sealing tape) is also suitable as an alternative.

Storage:
Protect from daylight/UV radiation, do not store below 60 % humidity and at room temperature.
